XRAY 300023 T4 2017 Specs  [XR-300023]

Dimensions

• Class: 1/10 electric touring car
• Width: adjustable 189 mm
• Length: 372 mm
• Wheelbase: adjustable 256-260 mm
• Weight: cca 481 g
• Ready-to-run fat: cca 1377 g

Chassis

• Chassis: CNC machined 2.2 mm laminated carbon graphite
• Shock towers: machined 3.0 mm laminated carbon graphite (front part + straight back) with many surprise mounting and camber url roll center positions
• Body: perhaps not included, utilizes 190 mm type

Drive train

• Type: dual belt
• Main layshaft: lightweight aluminum center layshaft with 20T pulleys and 84T 48P spur gear
• Primary: pinion/spur
• Drive ratio: 1.9
• Drive shafts: rebuildable front ECS driveshafts 52mm produced from unique world-renowned, top-secret, self-developed HUDY Spring SteelTM; super-lightweight straight back 50mm aluminum drive shaft s CNC-machined from premium Swiss 7075 T6 and hardcoated for extra durability and fashionable looks
• Front axle: front XRAY Composite Solid Axle with 38T pulley
• Rear differential: gear differential
• Belts: ultra-thin Kevlar belts
• Bearings: synthetic covered high-speed bearings

Suspension

• Front: graphite front suspension hands, hard steering obstructs
• Rear: graphite straight back suspension system system arms, difficult back uprights
• C-blocks: medium 4° caster obstructs
• Shocks: XRAY Short minimal Profile aluminum coil-over shocks paid off for improved suspension system travel

Geometry

• Camber: adjustable front component + rear
• Front caster: 4° fixed (optional 0°, 2° or 6°) with .5° ~ 2° adjustability utilizing squat/dive
• Toe-in: adjustable front side + rear
• Downstops: adjustable front side + rear
• Front anti-dive: adjustable 0° ~ 2°
• Rear anti-squat: adjustable 0° ~ 2°
• Anti-roll bars: 1.4mm front part + 1.3mm rear
• Ackermann: to change Ackermann angle, usage 2 identical shims (of identical level) relating to the aluminum steering dish and ball end
• Steering: centrally-positioned twin steering system

Other

• Wheels: not included
• Tires: not included
• guidelines: full-color manual with 3D pictures:
• Set-up guide: maybe not included, the T2 2-color set-up guide (44 pages) are installed consequently shows previous XRAY models in photographs included within it. Even so the methodology and set-up concept are the same for several contemporary touring cars
• Packaging: carton industry with plastic bags with parts
• Additionally included: HUDY Graphite Grease, Silicone sebum, Authentication Certificate, set-up sheet, components list & exploded view, decals
• Not included: radio system (transmitter and receiver), steering servo, engine, pinion gear, battery, speed controller, charger, 1/10-scale bodyshell (190 mm), tires, tires, inserts, high-strength fibre tape, double-sided tape, CA glue, bearing oil, medium-grade (blue) threadlock, tools
