XRAY 320203 - Xray T2D 2019 - 2WD 1/10 Electric Stadium Truck - Dirt Edition  [XR-320203]

XRAY XT2
1/10 DELUXE STADIUM TRUCK 2WD

2018 All-new

• Recent EOS Champion and united states Champion platform
• All-in-one concept  includes certain elements to create the XT2 for particular track conditions on either Carpet or Dirt:

- Both types of gearboxes and engine dishes enabling placement linked to engine in reduced position (Carpet) or top destination (Dirt)

- Gear differential (carpeting) and ball differential (dirt)

- Two different hardness of suspension system arms: medium (Dirt), difficult (carpeting)

- Two different rear shock towers: composite (carpeting), graphite (Dirt)

- Both forms of composite battery power straps to suit two various gear containers

- Both kinds of composite mounts for top brace to suit two various gear containers

- Composite gear cover to shield kit package from dust

• Unique smaller front composite framework front side brace enables mounting of new graphite component guard brace to change front chassis flex
• New graphite framework part guard brace for increased security and performance
• New protected steering linkage mounting increases dependability through the steering assembly
• New shock absorber paid down shims offer more accurate surprise shaft movement
• New shock absorber O-rings for better sealing and surprise performance
• New suspension system pin washers prevent the suspension system pins from hitting theaters, increasing dependability

General

• Recent EOS Champion and USA Champion platform
• All-in-one concept  includes particular components generate the XT2 for certain track conditions on either Carpet or Dirt:
• Both kinds of gearboxes and engine meals allowing positioning concerning the motor in lower spot (Carpet variation) or top spot (Dirt Edition)
• Gear differential (carpeting Edition) and ball differential (Dirt version) included
• Based on ultra-successful XB2 platform
• Full compatibility and interchangeable parts
• Designed for greatest performance anyway levels of racing
• Engineered with once you understand of smallest details
• Manufactured with prominent imaginative craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant
• Super an easy task to create, arranged, maintain, and drive
• Developed, produced, and styled by European Champion Martin Bayer and Dipl. Eng. Juraj Hudy, produced totally by XRAY in Countries In European Countries on planet's sophisticated RC manufacturing facility
• Setting the current standard for premium quality, reliability and performance
• Premium XRAY solution & support

Chassis

• Optimal framework fat blood supply & balance
• Both kinds of gearboxes and motor dishes permitting keeping with this motor in paid off destination (carpeting Edition) or top position (Dirt Edition)Original XRAY Multi-Flex™ technology for simple framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework: lightweight, strong, rigid
• Electronics design permits going the batteries frontwards/rearwards, and utilizing standard or mid-size servos and either utilizing chair pack or short pack batteries
• Composite part guards are a fundamental element of the XT2 Multi-Flex™ system
• Shorter front composite chassis front side brace enables mounting of new graphite side guard brace to change front framework flex
• Custom-designed front reduced framework brace, obtainable in moderate and hard hardness for particular track conditions
• Front security bumper
• Custom-designed top deck, accessible in moderate and hard hardness for specific track conditions
• Swiss 7075 T6 aluminum engine plate
• Both forms of composite battery straps to fit two various gear containers with foam spacer
• Lightweight, strong composite surprise towers with many shock mounting jobs (carpeting Edition) & graphite rear surprise tower (Dirt Edition)
• Pre-drilled centerline holes for simple balancing because of the HUDY Chassis Balancing Tool #107880

Drivetrain & Differentials:

• Conventional gear-driven 2WD off-road arena truck
• Unique gear field, Gear Box and motor dish with lowered top shaft, forward-shifted engine for improved steering and handling on higher-traction surfaces
• Included back gear differential with adjustable oil viscosity, 53T gear & inside satellite gears (Carpet Edition)
• Included externally-adjustable ball differential, 53T gear & axial bearings (Dirt Edition)36T (carpeting Edition) & 25T (dirt Edition) graphite composite idler gears
• 20T super-lightweight Swiss 7075 T6 hardcoated aluminum top shaft
• Robust slip-adjustable clutch with 81T primary spur gear molded from exclusive secret mixture of composite material
• 3-pad slipper clutch with ultra-efficient SLS product for more efficient & exact slide modification, and HUDY Spring Steel™ hardened outdrives for extra lifespan and reliability
• Constant velocity drives (CVD) are produced from unique HUDY Spring Steel™ for paid fat and increased durability
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 and also black-coated have actually ultra-true hex clamping design which guarantees solid mounting of wheel
• Full set of 22 high-speed, blue-sealed ball-bearings are used through drivetrain to be certain maximum effectiveness, degreased and oiled with AeroShell® Fluid 12 for maximum smoothness and stamina

Suspension

• Integrated Suspension system Settings (I.S.S.) for quick & effortless suspension system system geometry developing utilizing eccentric bushings put into Swiss 7075 T6 aluminum suspension system system holders
• Specially-designed suspension system elements made from cautiously developed personalized composite mixtures to ensure appropriate flex and durability
• Race-perfected suspension system geometry for superior performance and flexibility in a lot of competition conditions.
• Suspension hands are located in moderate, difficult and graphite hardness for particular track conditions
• Suspension elements: steering blocks, caster obstructs and uprights can be found in medium and hard hardness for specific track conditions
• Lower composite supply install with built-in 26° kick-up angle; optional aluminum and steel supply mounts available
• Lightweight, rigid caster obstructs has the capacity to do different basic caster angles making use of included caster bushings
• Tiny yet tough steering obstructs consists of composite steering obstructs + graphite Ackermann extensions
• Adjustable fat stability & wheelbase via included shims on external suspension system pins
• Compact straight back uprights with 0° toe and 6 various top roll center positions
• HUDY Spring Steel™ product for turnbuckles (featuring a tougher core) is employed for front side & rear upright linkages, and steering system.
• Front anti-roll club made of unique spring steel item to aid the vehicle at front part is set up towards leading human anatomy mount & could be just modified via linkages; laser-engraved markings for simple recognition, accessible in different sizes for fine-tuning
• Optionally available right back anti-roll club set to assist a large part associated with car; effortlessly modified via linkages; laser-engraved markings for simple identification, easily obtainable in different sizes for fine-tuning
• Suspension pin washers stop the suspension system system pins from being released, increasing reliability

Steering

• Simple yet effective dual-arm steering system
• Secure steering linkage mounting increases reliability of steering assembly
• Fully bearing-equipped with 8 high-speed ball-bearings for extremely exact steering
• Easily-adjustable Ackermann by fast changing the steering link mounting jobs regarding steering plate
• Bump guide modification for a great deal more aggression
• Ackermann modification via included shims or using different graphite expansion dishes on steering blocks

Shocks

• constant, dependable, membrane-free shocks with bleed-screw shock restriction design function up-stop & downstop modification via shims (under surprise collar, and under pistons, correspondingly)
• Swiss 7075 T6 aluminum surprise systems, paid off nut & bleeder shock caps
• Super-precise molded Delrin™ pistons can be had with 2-hole & various diameters (1.6mm & 1.7mm) for exact surprise modification, for customized modification, an accumulation blank pistons (no holes) will also be included
• Shock rods are machined from a certain steel item, accuracy hand-ground for maximum smooth operation and also hardened for increased lifespan
• Premium shock springs designed specially to match the XT2 shocks; manually calculated, selected and matched into pairs to make sure equal size and damping faculties; laser etched for simple identification
• Full style of linear -or- modern surprise springs available
• Premium silicone sebum laboratory tested and calibrated to be sure optimum determination and quality

Body, Wings, Wheels:

• High-downforce, low-profile aerodynamic Lexan™ human body designed to completely fit the XT2, features high-downforce areas (including front screen and top roof movement networks) for appropriate venting, and component downforce areas for greater safety.
• Tough composite component guards work double-sided Velcro™ tape to seal the body totally towards chassis and seal against dirt.
• Effective straight back wing finished up being designed to work entirely utilizing the XRAY XT2 body. Created from strong Lexan™ material, the wing is supported on wing mounts by extra flat shims to raised help and expand residing about the wing.
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to get rid of deformation and molded from in fact flexible material to retain type even with impacts (available as option merely)

Assembly, Set-up & help:

• Premium 3D full-color guide & additional sheets
• To entirely understand the set-up possibilities we recommend the most popular HUDY Set-up Book which can be packed with over 40 pages of top-notch pictures and easy-to-read RC vehicle set-up explanations
• Exclusive Virtual online Setup Sheet database with and endless range of set-up sheets for battle tracks throughout the world
• Premium, unmatched XRAY on line support

Adjustment opportunities:

• Fully-adjustable front component and back suspension system system system geometry: caster, camber, right back toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, Multi-Flex™
• Adjustable right back differential action
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & straight back upper links)
• several upper & paid off surprise mounting areas at front & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front part anti-roll bar
• Optional adjustable backside anti-roll bar
• Chassis pre-drilled holes for fat safety modification
