XRAY 350600 GTXE [XR-350600]

Price:

£572.60

Brand:

XRAY

Model:

XR-350600

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Electric Powered category

Write a review

alt="XRAY 350600 GTXE" title="XRAY 350600 GTXE"

Description

Dimensions

Length: 510 mm
Chassis size: 400 mm
Wheelbase: 318 ~ 326 mm
Width: 300 mm
Weight: 2155 g
Approximate operating weight: 3320 g

Chassis

Chassis: 3 mm CNC-machined Swiss 7075 T6 hardcoated aluminum
Radio tray: CNC-machined 2.2 mm graphite
Radio situation: Composite
Front top deck: CNC-machined 2.5 mm graphite
Central diff upper deck: CNC-machined 2.5 mm graphite
Braces: Composite braces (front part / back)

Suspension

Suspension: XPBS totally adjustable suspension
Rear suspension system: Lower H-arm with adjustable top camber link A arms
Front suspension system system: Zero kingpin suspension system system ball suspension system, 0-7° kingpin plate
Rear upright: Composite with twin arm mounting and 2 paid off roll center functions and top aluminum plate with 4 top roll center functions and adjustable roll center height with adjustable shims
Shocks: Big-bore shocks with various shock pistons featuring Delrin pistons
Shock towers: front side 3.5mm graphite, straight back 3.5mm graphite

Drivetrain

Type: Full-time shaft-drive 4WD
Primary: metal spur gear / pinion
Drive shafts: HUDY Spring metal CVD drive shafts
Central shafts: HUDY Spring metal CVD drive shafts
Differentials: Sealed, 6 gear, silicone-filled
Bearings: Rubber-sealed

Gearing

Pinion: 14T front part / rear
Crown gear: 46T front / rear
Pinion gear: Hardcoated aluminum 19T-24T
Spur gear: Composite 48T, 49T, 50T

Body, Tires, Wheels & Misc

Body: Optional #359730 GT Body maybe not included
Tires: not included
Wheels perhaps not included

Adjustment possibilities

Standard modification: Camber, caster, toe-in, wheelbase, kick-up, anti-squat, lower & top roll facilities, kingpin, Ackermann, bump steer, Multi-Flex, fat security

Items Not Included

Electronics (broadcast, Receiver, Servo, Batteries, Speedo), Wheels, Tires, Tools, Wheel device, , , Paint, Charger, Universal unit for many peanuts and turnbuckles, Set-up guide

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
