XRAY 350601 - Xray GTXE.2 - 1/8 Luxury Electric On-road GT Car  [XR-350601]

XRAY GTXE

Chassis

• CNC-machined framework created from 3mm top-quality Swiss 7075 T6 aluminum
• Strategically machined for ultra-light fat and uncompromised energy & rigidity
• Pre-drilled centerline holes to be used with HUDY Chassis Balancing Tool
• 1-piece, lightweight, easy-to-remove electronic devices assembly
• Front & rear framework braces for adjusting framework tightness & flex
• Large, easy-access, molded battery plate
• Super-strong diff bulkheads house the differentials and provide mounting points for suspension system system mounts and shock towers
• Extra-thick, premium-grade graphite shock towers include numerous surprise mounting positions
• Compact front part foam bumper produced from high-resilience, lightweight foam
• Front top bumper owner & paid off composite bumper are molded from rigid composite to withstand difficult crashes

Motor

• High-grade, CNC-machined 2-piece aluminum motor mount for simple gear mesh modification

Drivetrain

• Conventional shaft-driven 4WD drivetrain
• Front & rear gear differential with adjustable oil viscosity featuring 46T top gears and 14T pinion gears
• Center solid axle
• front part, straight back, and primary CVD drive shafts made from HUDY Spring Steel™
• Central outdrives function protective plastic footwear, dense 3mm pins, and a protective locking ring
• Rubber-sealed composite differential housings with metal inserts.
• Pressed metal interior diff gears, temperature addressed & machined for ultra-high accuracy and smooth operation
• Diff gears made from unique HUDY Gear Steel
• Super-lightweight, hardened diff outdrives produced from HUDY Spring Steel™
• Ultra-lightweight 17mm wheel hex drive hubs re CNC-machined from Swiss 7075 T6 black-coated aluminum
• Full number of 22 high-speed, lightly-oiled, blue-sealed ball-bearings make sure maximum efficiency
• Solid shaft produced from tough HUDY metal that's additionally temperature addressed for extra energy and endurance.
• Central transmission outdrive adapters produced from hardened metal gear adapter CNC-machined from Swiss 7075 T6 with for super-precise and wobble-free spur gear mounting

Suspension

• Ultra-robust XRAY Pivot Ball Suspension XPBS™ with built-in suspension system system system geometry adjustment
• Integrated Suspension Settings™ (I.S.S.) for fast & easy suspension system geometry setting
• Suspension fingers with optimal length, thickness, freedom, geometry of suspension system system points, and product traits.
• Super-lightweight composite steering obstructs + rigid Swiss 7075 T6 kingpin plate
• Easily-settable kingpin meal provides either 0° or 7° angle
• Optional kingpin meals available
• Ultra-tiny composite back uprights + rigid Swiss 7075 T6 mounting plate
• Extra-strong & robust front side side part upper arms
• Exclusive composite mixtures developed in-house by XRAY give you the perfect protection between reliability and performance
• Turnbuckles made from unique blend of HUDY Spring Steel™ especially formulated for turnbuckles
• Front & backside anti-roll bars created from springtime steel product

Steering

• Dual-arm steering system with adjustable Ackermann
• Swiss 7075 T6 aluminum steering plate
• Quick & easy Ackermann and bump steer modification

Shocks

• Big-bore shocks for ultimate dependability and performance
• 18.5mm outer-diameter hardcoated shock bodies
• Shock human body outside threading allows fast & effortless springtime preload adjustment
• Ultra-precise big-bore 6-, 8- and 10-hole surprise pistons produced from Delrin™ product for smooth procedure and durability
• Shock springs are your self determined, chosen and matched into pairs to make sure exactly equal size and damping characteristics
• HUDY Exclusive Silicone sebum are stated in European countries, and every batch of is laboratory tested and calibrated to make sure the most dedication and quality batch-to-batch. On the basis of the industry-standard cSt rating, the natural oils might an easy task to figure out, adjust, and feel.

Body & Wing

• XRAY self-designed GTX human anatomy (optional) produced from top-notch Lexan™ item features high-downforce areas for appropriate airflow and enhanced stability
• Molded wing struts (3) for additional durability and superior mounting
• High-strength wing

Assembly & Support

• Premium 3D full-color Instruction Manual
• Premium, unmatched XRAY on the web help

Adjustment Possibilities:

The GTXE features fully-adjustable front and back suspension system system geometry. For fast & effortless modification, we suggest using set-up tools and add-ons from HUDY, the world frontrunner of RC tools.

The significant and impressive selection of modification opportunities includes:

• Caster
• Camber
• Toe
• Kick-up
• Anti-dive
• Anti-squat
• Ride height
• Downstops
• Track-width
• Roll centers
• Bump steer
• Wheelbase
• Ackermann
• Adjustable shocks
• Adjustable front side part & right back diffs

All specs have reached the mercy of change without past notice. Pre-production model is shown, final specifications may somewhat vary. In some photos optional elements might shown. All option parts aren't included and should be purchased individually. And of some aluminum elements can vary greatly from kit to kit and several for this kits cannot consist of all orange or black colored colored components as shown. Several of the additional elements or choice parts may not be offered at when to the orange or black color as shown. The race body can be had in the same manner an option and it's not within the field.
