XRAY 360007 XB4 20  [XR-360007]

XRAY XB19

2018 All-new:

• Recent EOS Champion, European Champion, United States Of America Champion and World Champion platform
• Redesigned chassis accommodates groundbreaking reduced motor mount to diminish the CG
• Lower motor mounts reduce steadily the fat place of engine and primary slipper clutch/diff, increasing cornering price and stability
• Redesigned paid off composite main bulkhead fits the newest lower aluminum engine mount
• Redesigned component guard allows engine to be positioned lower
• Improved shock absorber reduced shims give more precise shock shaft movement
• Improved construction and production correctly both front side & rear differential top gears causes quieter procedure and increased dependability

General:

• Designed for greatest performance anyway examples of racing
• Engineered with consider smallest details
• Manufactured with popular artistic craftsmanship from premium European materials
• EFRA, ROAR, FEMCA spec compliant for stock and modified racing
• Super easy to build, setup, keep, and drive
• Developed, developed and styled by Dipl. Eng. Juraj Hudy, produced entirely by XRAY in Europe regarding planet's innovative RC manufacturing facility
• Revolutionary off road platform with groundbreaking standard for premium quality, reliability and performance
• Premium XRAY solution & assistance

Chassis:

• Smarter chassis fat balancing options permit the motor mount and center diff make to move frontwards or backwards
• Unique XRAY Multi-FlexTM technology for easy framework flex adjustment
• Swiss 7075 T6 hardcoated 2.0mm aluminum framework with countersunk holes for flush, smooth underside
• Tough composite part guards totally fit the framework to seal against dirt and protect from component impacts
• Compact electronics plate allows mounting the cost controller for fast & easy decrease and assembly
• Graphite front, primary & back top decks separate from framework flex modification and work simply included in the front side, main, and back diff assemblies
• Composite & graphite framework braces for fine-tuning of framework flex
• Independent servo mount enables the steering servo become installed on framework without pressing it, ensuring the reduction of unwanted framework tweak and enhancement of basic traction
• Two various battery pack straps brief -or- extended included. The long battery band permits battery become put up either frontwards or rearwards
• Battery foam back spacer guarantees the battery power won't fall out
• Thick 3.5mm graphite front surprise tower & 3.0mm back surprise tower with multiple surprise mounting and roll center positions
• Extra robust front side & backside bulkheads allow usage of the differentials only using 4 screws

Differentials & Drivetrain:

• Front & back gear differentials with adjustable oil viscosity, featuring 35T top metal gears and 14T steel pinion gears
• Molded front & backside gear differentials for super-smooth, maintenance-free procedure, features long-lifespan HUDY Spring Steel™ outdrives

• Innovative aluminum engine mount enables frontwards or rearwards motor place for fat stability adjustment
• Motor eccentric mounting dish inserts into an engine holder/drivetrain support, allowing fast & simple engine rotation for gear mesh and safeguarded clamping with just one screw

• Robust main slip-adjustable clutch with 81T primary spur gear molded from exclusive key mixture of composite material
• Internal 1:2.5 drive ratio
• 3-pad slipper clutch with ultra-efficient SLS material for a lot more efficient & precise slip modification, and HUDY Spring Steel™ hardened outdrives for additional lifespan and reliability
• Constant velocity drives (CVD) are made of special HUDY Spring steel for paid fat and increased durability. The shafts are hand ground for maximum precision
• Safety collars for several CVD drive shafts to hold mounting pins firmly in place
• Ultra-lightweight 12mm wheel hex drive hubs CNC-machined from Swiss 7075 T6 as well as black-coated have ultra-true hex clamping design which guarantees solid mounting linked to the wheel
• Optional 14mm offset wheel hex drive hubs readily available for super-fine track-width adjustment: -0.75mm, 0mm, +0.75mm and 12mm optional wheel hex drive hubs: -0.75mm, +0.75mm, +1.5mm, +2.25mm, +3.00mm, +3.75mm, +4.5mm
• Full couple of 22 high-speed, blue-sealed ball-bearings used through drivetrain to make sure maximum effectiveness, degreased and oiled with Aero Shell® Fluid 12 for maximum smoothness and longevity

Suspension:

• Swiss 7075 T6 aluminum suspension system holders front and rear
• Integrated Suspension system system Settings (I.S.S.) for fast & simple suspension system system geometry developing utilizing eccentric bushings placed into aluminum suspension system system holders
• Specially-designed suspension system elements made of very carefully developed tailor-made composite mixtures to make sure appropriate flex and durability
• Race-perfected suspension geometry for superior performance and freedom generally in most competition conditions.
• Lightweight 1-piece caster obstructs with preset 9° caster with effortless adjustable roll center location featuring bigger areas for simple and fast disassembly of CVDs; optional 6° & 12° caster obstructs available
• Front framework function pre-angled caster of 8° combined with adjustable I.S.S. settings a mixture 16~20° of total caster could be achieved
• Tiny yet robust steering obstructs molded from a particular composite mixture for maximum power featuring adjustable reduced roll center.
• Very compact 0° toe-in back uprights function 3 different top roll center roles, staggered inner/outer bearing sizes for improved load support and unsprung fat, and wheelbase adjustability via included shims
• Oversized outside bearings in uprights to for increased powerful loads
• HUDY Spring SteelTM material for turnbuckles (featuring a tougher core) works extremely well for front component & rear upright linkages, steering system, and servo saver
• Anti-roll bars constructed from unique springtime metal product to steer the auto at both front part and right back are installed towards diff instances & can be simply modified via linkages; laser-engraved markings for simple recognition, available in various sizes for fine-tuning

Steering:

• Simple, effective dual-arm steering system with built-in adjustable servo saver guarantees perfect steering and easy Ackermann and bump steer modification

Shocks:

• Consistent, dependable membrane-free big-bore shocks with bleed-screw surprise limit design function up-stop shock pole travel adjustment (via O-rings) and downstop modification (via shims under pistons)
• Swiss 7075 T6 aluminum shock figures, lower nut & bleeder shock caps are hard coated
• Super-precise molded Delrin™ pistons can be found with 2-hole design & opening diameters 1.6mm and 1.7mm for accurate surprise modification; for personalized modification, some blank pistons (no holes) will also be included
• Shock rods are machined from a particular metal product, precision hand-ground for maximum smooth procedure as well as hardened for increased lifetime
• Shock springs are smaller enabling more fine trip height modification; by hand determined, selected and matched into pairs to ensure equal size and damping characteristics; laser etched for simple recognition. Two types of springtime sets are included in the kit.
• Full form of linear -or- modern shock springs available
• Premium silicone natural oils laboratory tested and calibrated to be sure maximum consistency and quality

Bumper, Body, Wheels:

• Strong composite back wing holder
• Front paid off bumper protrudes from base regarding framework to take in all effects from contact betwixt your framework and the track surface
• Beefy 6mm dense human body articles from unique composite product for optimum strength
• High-downforce XB4 human body is superior, low-profile, and aerodynamic to totally fit the XB4 layout, with front display and top roof motion stations for appropriate venting, and component downforce areas and top primary rib for greater stability
• Specially produced 12mm hex hub tires for high-competition competition; featuring reinforcement ribs to eradicate deformation and molded from actually versatile item to retain form even with impacts

Assembly, Set-up & Help:

• Premium 3D full-color Instructions & supplementary sheets
• To grasp the set-up possibilities we recommend the famous HUDY Set-up Book that will be laden with over 40 pages of top-quality pictures and easy-to-read RC car set-up explanations
• Exclusive Virtual On Line Setup Sheet database with tens and thousands of set-up sheets for race songs throughout the world
• Premium, unmatched XRAY online help

Modification Possibilities:

• Fully-adjustable front side and right back suspension system system geometry: caster, camber, toe, kick-up, anti-squat, ride height, downstops, track-width, roll center, wheelbase, roll facilities, Multi-Flex™
• Adjustable front part & rear gear differential action (via oil viscosity)
• Adjustable slipper clutch
• Adjustable HUDY Sprint Steel™ turnbuckles (steering, front & right back top links)
• several upper & reduced shock mounting areas at front side & rear
• Adjustable Ackermann and bumpsteer
• Adjustable front side & rear anti-roll bars
• Chassis pre-drilled holes for fat security adjustment
