XRAY 370008 X12 2018 US Specs [XR-370008]

Price:

£273.43

Brand:

XRAY

Model:

XR-370008

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Pan Cars category

Write a review

alt="XRAY 370008 X12 2018 US Specs" title="XRAY 370008 X12 2018 US Specs"

Description

Dimensions

Class: 1/12 electric pan car
Width: Adjustable 167mm +/- 2mm front side, 169mm rear
Length: 264mm (varies centered on right back tires utilized)
Wheelbase: 201 +/-0.5mm
Weight: 202 g
Ready-to-run fat: 840 g - incl. BL system (varies based on gear used)

Chassis

Chassis: EU version - 2.5mm carbon fibre, CNC machined; United States variation - 2.0mm Swiss 7075 T6 aluminum, CNC machined
Body: maybe not included, makes use of 1/12 pan automobile type

Drivetrain

Type: 2WD direct drive to rear axle
Rear Axle: Graphite shaft with ball differential
Primary: Spur/pinion
Bearings: High-speed ball-bearings (10)

Suspension

Front: Spring-supported, kingpin-style front suspension system with upper & reduced suspension system system fingers and steering blocks
back: Articulating straight back engine POD adjustable via pivot-ball links, managed by rear shock absorber.
Rear Shock: Central adjustable oil-filled shock absorber

Geometry

Ride Height: Adjustable front + straight back
Wheelbase: Adjustable
Camber Adjustable front
Front Caster (Static): 114.5° static adjustable fixed caster
Front Caster (Reactive) 2.57.5° adjustable reactive caster
Track-width: Adjustable front component and rear
Toe: Adjustable front
Downstop: Adjustable rear
Ackermann: Adjustable with shims
Bumpsteer: Adjustable with shims
Steering: Direct linkage between steering servo saver and steering obstructs
Balance: Front/rear weight balance adjustable via battery pack spot

Other

Wheels: not included
Tires: not included
guidelines: Full-color guide with 3D visuals
Set-up guide: Printed variation maybe not included. Latest full-color Set-up guide (16 pages) are set up from XRAY internet site. Set-up Book shows previous XRAY models in photographs contained within it, even so the methodology and set-up concept are a similar for many 1/12 pan vehicles.
Packaging: Carton box with synthetic bags with parts
Additionally included: HUDY Diff Grease, Authentication Certificate, elements list & exploded view, decals, oils
Not included: Motor, batteries, cost controller, tires, human body, steering servo, radio gear, tools

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
