XRAY 370703 X1 2018 Specs [XR-370703]

Price:

£309.57

Brand:

XRAY

Model:

XR-370703

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Formula Cars category

Write a review

alt="XRAY 370703 X1 2018 Specs" title="XRAY 370703 X1 2018 Specs"

Description

Dimensions

Class: 1/10 formula
Width: Adjustable 180mm front part, 185mm straight back (will depend on tires used)
Lenght: 410 mm
Wheelbase: 264 mm
Weight: 375 g
Ready-to-run fat: 985 g (varies determined by equipment used)

Chassis

Chassis: 2.5 mm carbon fibre, CNC machined
Body: XRAY X1 1/10 formula kind

Drivetrain

Type: 2WD direct drive to rear axle
Rear Axle: steel shaft with ball differential
Primary: Spur/pinion
Bearings: High-speed ball-bearings (13)

Suspension

Front: Spring-supported, kingpin-style front side part suspension system with composite steering obstructs and graphite upper & paid down suspension system system arms
back: traditional back pod, adjustable via pivot-ball links, handled by component tubes
Rear Shock: Central adjustable oil-filled shock absorber

Geometry

Ride Height: Adjustable front + rear
Camber: Adjustable front
Front Caster: 312° adjustable caster
Track-width: Adjustable front + rear
Toe: Adjustable front
Downstop: adjustable front part + rear
Anti-roll club: 1.2 mm front
Ackermann: adjustable with servo saver supply and steering block
Steering: Direct linkage between steering supply and steering obstructs
Balance: Front/rear weight stability adjustable via battery destination

Other

Wheels: perhaps not included
Tires: Not included
guidelines: complete colour instruction manual
Packaging: Carton field with synthetic bags with parts
Additionally included: Lexan Formula body & front side wing, HUDY Diff Grease, Authentication Certificate, elements list & exploded view, shock oil
Not included: Radio system (transmitter and receiver), steering servo, engine, pinion gear, electric batteries, rate controller, charger, tires, tires, inserts, high-strength fibre tape, double-sided tape, CA glue, bearing oil, tools

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
