XRAY 370704 X1 2019 Specs  [XR-370704]

XRAY X1

1/10 DELUXE ELECTRIC FORMULA

2018 All-new:

• All-new super-narrow framework design is 24mm narrower to eliminate framework experience of the track while rolling
• All-new redesigned component hyperlink adaptors – machined from graphite – are installed to aluminum actually appears working alongside brand-new super-narrow chassis
• All-new steering obstructs with new additional Ackermann place for substantially more in-corner steering and almost 100percent Ackermann curve
• All-new shock adaptor for fast & easy shock place improvements; groundbreaking frontward spot for improved drivability over bumps and enhanced on-power traction
• All-new graphite servo owner enables mounting of new surprise adaptor
• All-new tweak-free pivot brace for quicker & easier pod meal mounting
• All-new back url brace with longer leads for battery component end permits 5mm modification of battery position
• All-new electric batteries backstop mounting allows battery pack spot adjustment
• Current most readily useful doing 1/10 formula automobile: 2x European Champion, 3x ETS Champion, Snowbird Champion, IIC Champion, and plenty of nationwide championship titles
• Platform (including many elements) works with previous X1 versions
• 2018 variation dedicated to fine improvement of little details, making the car a total champion from the container

General:

• XRAY 1/10 Formula battle vehicle with authentic 100per cent self-developed XRAY elements, designed and manufactured elements by XRAY in Europe
• Legendary XRAY premium design, workmanship & item quality and unmatched focus on the best details
• Simple yet effective and proven design, well thought-out details, unmatched accuracy in most details
• High-competition design with focus on ultra-low fat, leading to super-lightweight construction
• Optimized for indoor carpeting rushing and outside asphalt racing
• Elegant in ease of use & effectiveness, the X1 is positioned to get to be the new standard in 1/10 Formula race

Chassis:

• CNC-machined from custom-manufactured 2.5mm high-grade graphite product with a specially-designed ingredient for carpeting race and asphalt racing
• Super-narrow framework front part permits optimum traction while maintaining sufficient steering and cornering speed
• Chassis design has optimal tightness for exemplary administration, freedom for optimum traction, and ideal torsional stability
• Superb managing on either interior or outside tracks, on carpeting or asphalt

• Improved steering effect and optimal side-to-side weight transition
• Rear graphite brace holds battery constantly in place, and offers a great mounting base the optional part shock
• Battery placement could possibly be quickly changed from inline to cross-chassis, to produce perfect fat stability dependent on track conditions; composite battery pack backstops prevent battery pack motion
• Cross-chassis battery placement has adjustable destination around 5mm too because of the adjustable electric batteries backstop inside framework
• Laydown steering servo orientation for cheapest CG at framework center
• Front center shock mount is dependant on the absolute chassis center for perfect side-to-side fat transfer
• Chassis and right back pod function pre-drilled centerline holes for maximum fat safety modification using HUDY Balancing Tool #107880

Front suspension system system:

• Strong, simple, entirely adjustable, yet smart and ultra-efficient front side suspension system
• High-grade graphite paid off & upper suspension system system system arms and provide mount plate
• Tiny, strong composite pivot balls for smooth, bind-free operation
• Adjustable front caster via eccentric bushings for front top meal:  3°, 6°, 9°, and 12°
• Adjustable front camber via eccentric bushings for front top arms:  1.0°, 1.5°, 2.0°, and 2.5°
• Front adjustable anti-roll club with optional complete variety of cables for fine tuning
• Adjustable front part upper & paid down roll facilities via included shims
• Adjustable front track-width modification via included wheel axle shims

Steering:

• Independent drifting servo mounting system: selection of split or fixed position
• Tiny, robust 4-spring servo saver protects the servo from effect harm. Provides accurate steering and constant maneuvering, while making the vehicle easier to drive
• Pre-drilled framework holes to guide either a micro or mid-size steering servo
• Centralized servo destination for perfect steering faculties
• Centrally-positioned servo saver supply with selectable Ackermann positions
• Servo supply mounting: array of separate floating or standard mounting
• Adjustable bumpsteer characteristics via included shims
• Steering backstops set up on lower arms enable modification of maximum steering angle
• Super-tiny yet robust steering obstructs with additional new Ackermann jobs to acquire additional steering, and ultra-precise interior gap for kingpin guarantees wobble-free assembly
• Super-smooth hardened steel kingpins
• Adjustable, lightweight aluminum turnbuckles for front toe modification

Back pod:

• Compact, ultra-lightweight right back pod design with composite right back pod links situated nearer to chassis centerline
• Narrow back pod design provides enhanced steering reaction and optimal side-to-side fat transition
• CNC-machined pod bulkheads made from premium extra-hard Swiss 7075 T6 aluminum, in addition black coated for lengthy life and stylish look
• Rear pod upper meal made from strong graphite dinner could be the base the principal surprise, the working platform for the part pipes, and yes it links the key framework construction along with the straight back pod
• Rear wing graphite mount features numerous wing height mounting jobs also for better adaptation to different traction conditions
• Smart pod design accommodates all machines, allows super-easy engine access
• Pod pivot brace features an ultra-small and lightweight pivot ball for smooth movement
• Eccentric composite bushings are included for ultra-fine back trip height adjustment
• Lateral damper side pipelines for smoother, more constant operation
• Linear part springs for constant and smooth compression for smooth out-of component making, and reduced amount of traction rolling

Shock:

• Well-proven fast shock from T4 touring vehicle platform.
• Interchangeable interior elements, with fixed 1-piece accuracy pistons available with 3 different-diameter holes for damping modification: 1.1, 1.2, and 1.3mm with 3 and 4 holes
• CNC-machined Swiss 7075 T6 aluminum surprise human anatomy, hard-anodized, with fine outside threading for fast & effortless surprise springtime preload adjustment
• Super-soft silicone surprise O-ring for smooth procedure while preventing oil leakage
• Ultra-finely completed hardened surprise shaft
• Self-centering shims retain the shock O-rings, for perfect positioning to the surprise body
• Finely-threaded aluminum surprise paid off limitation secures the silicone O-rings and shims inside surprise body
• Super-soft silicone membrane layer, supported by a miniature foam pad, provides appropriate damping characteristics
• Aluminum surprise springtime collar allows fast & easy downstop adjustment
• The C=2.3 linear 3S surprise springtime supplies the best balance between traction, protection, and steering reaction; a whole number of optional springs can be obtained for further fine adjustment
• Complete array of springs including modern 3S springs (optional)
• Aluminum progressive shocks system for improved traction & steering (optional)
• New adaptor permits long surprise mounting for improved traction and better driving over bumps

Drivetrain:

• CNC-machined ultra-precise wheel axles produced from premium HUDY Spring Steel™ can also be hardened and hand-ground for accuracy fitment
• Ultra-strong lightweight hollow metal axle for maximum dependability and reduced rotational weight
• Rear differential with high-grade precision carbide balls for spur gear, hardened & precision-ground D-shaped metal shims, and premium carbide axial thrust-bearing
• Precision-molded spur gear made from XRAY's exclusive composite item, guarantees real working, super-quiet procedure, and robustness to be utilized with effective motors
• CNC-machined straight back hubs created from lightweight aircraft aluminum, specially lightened and black-coated for trendy looks
• Rear kept aluminum wheel hub features a center-balanced clamping mounting system, ensuring safe mounting while eliminating vibration and run-out
• Full set high-speed, blue-sealed, metal ball-bearings utilized through drivetrain and steering to make sure maximum efficiency. All bearings are degreased and oiled with AeroShell® Fluid 12 for optimum smoothness and long life
• Easy backside track-width modification via included shims

Body & Aerodynamics:

• Robust human anatomy articles installed on the solid platform on aluminum actually appears, featuring fully-adjustable human anatomy holders
• Multi-part front side spoiler consists of composite bumper and Lexan™ downforce spoiler
• Composite front side framework bumper is extremely rigid yet versatile to deliver superior protection
• Lightweight Lexan™ front component spoilers – number of low or high downforce spoilers for distinction track conditions
• High-efficiency, high-strength, adjustable-downforce straight back wing with adjustable mounting height position
• High-performance, low-profile aerodynamic X1 human anatomy produced from top-notch premium Lexan™ product for optimum flexibility generally in most monitor conditions. Straight back environment stations direct airflow onto rear wing. Body edges and cockpit sides are because flat feasible to direct airflow around the human anatomy for optimum protection. In to the rooftop, two movement stations are incorporated for appropriate venting. An integrated helmet guarantees your system is appropriate for occasions by which a pilot figure helmet is necessary.

Assembly & help:

• Highest quality of composite components guarantees super-precise fitment, easy installation, and smooth procedure on most parts
• Premium 3D full-color Instruction Manual
• Exclusive Virtual On Line Set-up Sheet database with several thousand set-up sheets for battle tracks across the world
• Premium, unmatched XRAY online help

Modification possibilities:

• Front camber, caster, and toe
• Front & backside track-width
• Front, center, and right back drive height
• Front springs
• Front anti-roll bar
• Fully-adjustable right back surprise absorber
• Downstops
• Side damper pipelines for lateral pod damping
• Chassis tweak
• Ackermann
• Bump steer
• Differential settings
• Battery position
• Front wing downforce
• Rear wing downforce
• Steering system
• Servo mount system
