XRAY 370705 X1'20  [XR-370705]

XRAY X1

1/10 DELUXE ELECTRIC FORMULA

2018 All-new:

• All-new super-narrow framework design is 24mm narrower to eliminate framework experience of the track while rolling
• All-new redesigned component url adaptors – machined from graphite – are installed to aluminum really stands to work well with brand new super-narrow chassis
• All-new steering obstructs with amazing extra Ackermann place for substantially more in-corner steering and almost 100percent Ackermann curve
• All-new shock adaptor for fast & easy surprise spot modifications; brand new frontward destination for improved drivability over bumps and improved on-power traction
• All-new graphite servo owner enables mounting of the latest shock adaptor
• All-new tweak-free pivot brace for quicker & easier pod meal mounting
• All-new backlink brace with longer leads for battery power component end permits 5mm modification of battery position
• All-new battery backstop mounting enables battery power destination adjustment
• Current most useful doing 1/10 formula car: 2x European Champion, 3x ETS Champion, Snowbird Champion, IIC Champion, and many nationwide championship titles
• Platform (including virtually all elements) works together past X1 versions
• 2018 variation specialized in fine enhancement of small details, making the automobile a complete champ appropriate from the box

General:

• XRAY 1/10 Formula competition car with authentic 100percent self-developed XRAY elements, created and manufactured components by XRAY in Europe
• Legendary XRAY premium design, workmanship & product quality and unmatched concentrate on the best details
• Simple yet effective and proven design, well thought-out details, unmatched precision in many details
• High-competition design with consider ultra-low fat, causing super-lightweight construction
• Optimized for interior carpeting competition plus outdoor asphalt racing
• Elegant in simpleness & effectiveness, the X1 is in the pipeline in order to complete up being the present day standard in 1/10 Formula racing

Chassis:

• CNC-machined from custom-manufactured 2.5mm high-grade graphite product with a specially-designed element for carpeting battle and asphalt racing
• Super-narrow framework front side side permits maximum traction while maintaining sufficient steering and cornering speed
• Chassis design has optimal tightness for exceptional managing, freedom for optimum traction, and perfect torsional stability
• Superb handling on either inside or outside tracks, on carpeting or asphalt

• Improved steering response and optimal side-to-side fat transition
• Rear graphite brace holds battery power set up, and an excellent mounting base the optional part shock
• Battery positioning could be quickly changed from inline to cross-chassis, available perfect fat balance based on monitor conditions; composite battery power backstops reduce battery pack motion
• Cross-chassis battery pack positioning has adjustable spot around 5mm besides because of the adjustable battery pack backstop inside chassis
• Laydown steering servo orientation for cheapest CG at framework center
• Front center shock mount lies inside absolute framework center for perfect side-to-side fat transfer
• Chassis and back pod function pre-drilled centerline holes for maximum fat security modification making use of HUDY Balancing Tool #107880

Front suspension:

• Strong, simple, completely adjustable, yet smart and ultra-efficient front side side suspension system system
• High-grade graphite paid down & upper suspension system system hands and arm mount plate
• Tiny, strong composite pivot balls for smooth, bind-free operation
• Adjustable front side caster via eccentric bushings for front part top meal:  3°, 6°, 9°, and 12°
• Adjustable front side camber via eccentric bushings for front top arms:  1.0°, 1.5°, 2.0°, and 2.5°
• Front adjustable anti-roll club with optional complete choice of cables for fine tuning
• Adjustable front top & paid down roll facilities via included shims
• Adjustable front side track-width modification via included wheel axle shims

Steering:

• Independent floating servo mounting system: array of split or fixed position
• Tiny, robust 4-spring servo saver protects the servo from impact harm. Provides accurate steering and constant maneuvering, while making the automobile simpler to drive
• Pre-drilled framework holes to aid either a micro or mid-size steering servo
• Centralized servo position for perfect steering traits
• Centrally-positioned servo saver supply with selectable Ackermann positions
• Servo supply mounting: selection of separate floating or standard mounting
• Adjustable bumpsteer faculties via included shims
• Steering backstops setup on paid down hands enable modification of optimum steering angle
• Super-tiny yet robust steering obstructs with additional brand new Ackermann roles for significantly more steering, and ultra-precise interior opening for kingpin guarantees wobble-free assembly
• Super-smooth hardened metal kingpins
• Adjustable, lightweight aluminum turnbuckles for front toe adjustment

Rear pod:

• Compact, ultra-lightweight straight back pod design with composite back pod links placed closer to chassis centerline
• Narrow back pod design provides enhanced steering effect and optimal side-to-side fat transition
• CNC-machined pod bulkheads created from premium extra-hard Swiss 7075 T6 aluminum, furthermore black colored coated for long life and trendy look
• Rear pod top meal produced from strong graphite meal could be the base the primary shock, the working platform the medial side pipes, looked after connects leading framework construction utilising the rear pod
• Rear wing graphite mount features multiple wing height mounting jobs even for better adaptation to different traction conditions
• Smart pod design accommodates all machines, allows super-easy engine access
• Pod pivot brace features an ultra-small and lightweight pivot ball for smooth movement
• Eccentric composite bushings are included for ultra-fine back journey height adjustment
• Lateral damper component pipes for smoother, more constant operation
• Linear side springs for consistent and smooth compression for smooth out-of part making, and reduction of traction rolling

Shock:

• Well-proven brief surprise from T4 touring automobile platform.
• Interchangeable interior components, with fixed 1-piece accuracy pistons that you can get with 3 different-diameter holes for damping adjustment: 1.1, 1.2, and 1.3mm with 3 and 4 holes
• CNC-machined Swiss 7075 T6 aluminum shock human body, hard-anodized, with fine outside threading for quick & effortless shock springtime preload adjustment
• Super-soft silicone shock O-ring for smooth procedure while preventing oil leakage
• Ultra-finely finished hardened surprise shaft
• Self-centering shims provide surprise O-rings, for perfect placement in surprise body
• Finely-threaded aluminum surprise paid down restriction secures the silicone O-rings and shims in surprise body
• Super-soft silicone membrane layer layer, supported by a miniature foam pad, provides proper damping characteristics
• Aluminum surprise springtime collar enables fast & simple downstop adjustment
• The C=2.3 linear 3S shock springtime supplies top stability between traction, safety, and steering effect; an overall total selection of optional springs can be had for further fine adjustment
• Complete array of springs including modern 3S springs (optional)
• Aluminum modern shocks system for improved traction & steering (optional)
• brand new adaptor allows long surprise mounting for improved traction and better driving over bumps

Drivetrain:

• CNC-machined ultra-precise wheel axles produced from premium HUDY Spring Steel™ are furthermore hardened and hand-ground for accuracy fitment
• Ultra-strong lightweight hollow metal axle for optimum reliability and reduced rotational weight
• Rear differential with high-grade accuracy carbide balls for spur gear, hardened & precision-ground D-shaped metal shims, and premium carbide axial thrust-bearing
• Precision-molded spur gear created from XRAY's exclusive composite item, guarantees genuine running, super-quiet procedure, and robustness become utilized with effective motors
• CNC-machined rear hubs made from lightweight aircraft aluminum, specifically lightened and black-coated for fashionable looks
• Rear kept aluminum wheel hub features a center-balanced clamping mounting system, ensuring protected mounting while eliminating vibration and run-out
• Full set high-speed, blue-sealed, steel ball-bearings used through drivetrain and steering to ensure maximum effectiveness. All bearings are degreased and oiled with AeroShell® Fluid 12 for optimum smoothness and long life
• Easy back track-width modification via included shims

Body & Aerodynamics:

• Robust human body articles installed on the solid platform on aluminum stands, featuring fully-adjustable human anatomy holders
• Multi-part front part spoiler have composite bumper and Lexan™ downforce spoiler
• Composite front side framework bumper is incredibly rigid yet versatile to provide superior protection
• Lightweight Lexan™ front spoilers – collection of low or high downforce spoilers for big difference track conditions
• High-efficiency, high-strength, adjustable-downforce back wing with adjustable mounting height position
• High-performance, low-profile aerodynamic X1 body created from top-notch premium Lexan™ item for maximum freedom in several monitor conditions. Straight back environment web sites direct airflow onto back wing. Body edges also cockpit edges are since flat as possible to direct airflow around the body for optimum protection. In the rooftop, two motion channels are included for appropriate venting. An essential helmet guarantees the body is suitable for occasions in which a pilot figure helmet is required.

Installation & help:

• Highest quality of all the composite parts ensures super-precise fitment, easy create, and smooth procedure of parts
• Premium 3D full-color Instruction Manual
• Exclusive Virtual on the web Set-up Sheet database with many set-up sheets for competition songs across the world
• Premium, unmatched XRAY on the internet support

Modification possibilities:

• Front camber, caster, and toe
• Front & right back track-width
• Front, center, and right back drive height
• Front springs
• Front anti-roll bar
• Fully-adjustable back shock absorber
• Downstops
• Side damper pipelines for lateral pod damping
• Chassis tweak
• Ackermann
• Bump steer
• Differential settings
• Battery position
• Front wing downforce
• Rear wing downforce
• Steering system
• Servo mount system
