XRAY 380003 M18 PRO LiPo - 4WD Shaft Drive 1/18 Micro Car [XR-380003]

Price:

£182.65

Brand:

XRAY

Model:

XR-380003

Not Available

Please kindly input your name and email address, we will inform you once we have the restocking.

Or you may find similar product under the
R/C Models - On-Road - Touring Cars - Electric Powered category

Write a review

alt="XRAY 380003 M18 PRO LiPo - 4WD Shaft Drive 1/18 Micro Car" title="XRAY 380003 M18 PRO LiPo - 4WD Shaft Drive 1/18 Micro Car"

Description

Dimensions

Class: 1/18 electric micro car
Front Width: 100 mm (adjustable with offset wheel axles)
back Width: 107 mm
Length: 220 mm
Wheelbase: 150 mm
Weight: 165 g
Ready to do fat: 440 g

Chassis:

Chassis: LiPo optimized framework CNC-machined from premium 1.6mm carbon fiber
Upper deck: revolutionary XRAY Multi-Flex tech top deck enables separate front/rear flex adjustment
Body: 150 mm micro body (included)

Drivetrain:

Type: shaft-drive 4WD
Drivetrain: aluminum primary driveshaft
Primary drive: pinion/spur
Drive ratio: 1:2.5
Drive shafts: composite front component + straight back
Differentials: composite ball differentials - adjustable front side + rear
Bearings: 20 high-speed ball-bearings

Suspension:

Front: entirely separate
back: fully independent
Dampening: friction-type coil-over shocks

Geometry:

Camber: front/rear: -1° (preset)
Caster: 6° (preset)
Front Toe: preset +0.5° (adjustable)
back Toe: preset 2.5° (adjustable)
Downstops: adjustable front part + rear
Anti-roll pubs: not included
Wheelbase: 150 mm

Others:

Wheels: touring car-style hex hub wheel mounting system
tires: mounted foam tires 50sh front side, 35sh back
guidelines: full-color manual with 3D images
Packing: carton package with 8 synthetic bags with components
Packing: certificate, components list & exploded view, set-up sheet, decals, driveshaft setup tool, hex hub construction tool
Not included: radio system (transmitter & receiver), steering servo, ESC, motor, LiPo battery power, battery charger, CA glue, Lexan paint, transmitter batteries, 3.0mm phillips screwdriver, 1.5mm allen wrench

Remark :

Due to limited stock availability, please notice that some XRAY items may have to order from the factory and the ready time is around 4-6 weeks. Customer purchases the item is assumed to accept the waiting time which allows us to order directly from the manufacturer if the item is out of our warehouse.
