Tamiya #58681 - 1/10 TC-01 Formula E GEN2 Vehicle Championship Livery (TC01 Framework)
Big awareness of the body and chassis that tell a fresh duration!
Formula E, also called “F1 for electric vehicles”. It has been held since 2014, primarily in metropolitan courses including famous resort areas, perhaps not generally speaking shut circuits. That's a power radio control car installation kit that reproduces the Formula E GEN2, a second-generation device developed with this competition and introduced in 2018. The reduced and unique style of leading and rear tires covered with a body cowl is realistically reproduced with polycarbonate. Separate parts are included the cockpit protective device “Hello”, rearview mirror, and big back diffuser which also acts as a bumper. Also, markings are split into black colored and silver, and an accumulation of stickers for the championship (official) color with a light blue line. The chassis, we adopted TC-01, a shaft drive 4WD with in-board suspension system system demands
Adopting shaft drive 4WD chassis with inboard suspension system, TC-01
The chassis makes use of shaft drive 4WD TC-01 with inboard suspension to be able to match the low automobile height. A motor is installed on center of a monocoque framework with high rigidity as well as the propeller shaft transmits energy forward and backward. Loaded with an oil-filled gear diff. 4-wheel separate double wishbone suspension system with long supply specifications. An inboard kind that runs a horizontal oil damper vertically with a push rod and rocker supply. By adjusting the total amount of spacers, you are able to set the camber angle, caster angle, and toe angle. Also, the suspension system system arms / uprights use typical parts regarding front part, right back, left, and to provide high maintainability.
Tamiya 58681 Specs:
Length 430mm
Width 188mm
Height 99mm
Wheelbase 257mm (exact same with TT-01 / TT-02)
Tire width / diameter = front part and back 24 / 64mm
Frame = integrally molded monocoque
Drive system = straight motor / shaft drive 4WD
Differential gear = oil-filled gear diff
Steering = 3-split tie pole type
Suspension = inboard sort 4-wheel dual wishbone
Damper = CVA oil damper both front and right back
Gear ratio = Kit standard 24T 6.56: 1
