Specs:
•Based on IFMAR/ROAR/EFRA/BRCA design demands.
•Modified winds, 13.5T, 17.5T, 21.5T machines are typical ROAR authorized ( BRCA pending).
•Motor proportions (Diameter x size) 35.8mm x 52.2mm.
•Shaft Diameter: 3.17mm
•Magnet Dimensions
12.3 x 5x 24.2mm(3.5T~9.5T),
12.5 x7.2x25.2mm (10.5T~21.5T),
12.3 x7.2x25.2mm (25.5T)
Variable timing end bell
•Weight: ~150g (varies between turns)
•Recommended RC Model automobile: 1:10 touring, Buggy, MINI vehicle.
Available Turns: 4.5T, 5.5T, 6.5T, 7.5T, 8.5T, 9.5T, 10.5T, 13.5T, 17.5T, 21.5T,25.5T - 3.5T purchase by request.
Improvements good Actinium V4 motor:
•Revised construction design for enhanced sensor precision.
•Revised stator meal profile with 3 screws holes sealed to enhance magnetic industry determination and effectiveness.
•Traditional three long construction screws changed with fast screws mounted to component from the end bell.
•Copper wiring purity increased for minimized opposition. Hand injury for maximum accuracy and effectiveness.
•Revised rotor magnetic item for improved energy, effectiveness and expand the fade out time.
•Motor can machining pages considerably revised from V4 to boost convection cooling.
•Collector band machined from proprietary alloy ultimately causing minimal opposition and optimum temperature dissipation.
