HOBBYWING FlyFun 60A V4 - 80020630  [HW-80020630]

Great Performance

Imported elements additionally the PCB (printed circuit
board) with exceptionally low impedance utilized by FlyFun ESCs gurantee
great present endurance, good performance and high dependability.

Programmale Parameters

With a rich pair of programmable parameters (via a Light-emitting Diode system
card/box), FlyFun ESC is relevant to different aircraft (like fixed-wing,
heli, multirotor and etc.)

Several Protections

Multiple security features have abnomal input
voltage, ESC thermal, throttle sign loss (or Fail secure), and low voltage
cutoff efficiently prolongs the clear answer life for the ESC.

Product Specification

Type

• Brushed/Brushless : BL
• High Voltage/Regular : Regular

Specifications

• Cont./Peak Present : 60A/80A
• Input : 2-6S LiPo
• BEC production : Linear mode:5V,3A
• Output Wires : Blue-14AWG-100mm*3
• Input Connectors : No
• Output Connecotors : 4.0 silver Connectors (Female)

ESC Programing via

• Transmitter : Supported
• LED Program Card : Supported
• LED Program Box : not Supported
• LCD Program Box : maybe not Supported
• WiFi Module : not Supported
• Program Port : Program/Throttle Wire

Firmware

• Firmware Upgrade : perhaps not Supported

Size & Weight

• Size : 83.0x31.0x16.0mm
• Weight : 63g
