Excellent engine Governing Speed
High-performance 32-bit processor with a running regularity of 72MHz
along with advanced level algorithm optimizes the speed governing.
Together with the adjustable governor parameters guarantees every
pilot an accurate control experience
High Voltage incorporated BEC
The integral switch mode BEC with a variable voltage (6V/7.4V for the Platinum
25A V4, 5V~8V with all the current step of 0.1V the Platinum 40A V4), a consistent present
of over 3A/7A (3A the Platinum 25A V4, 7A the Platinum 40A V4) and a premier
present of 7A/18A (7A the Platinum 25A V4, 18A the Platinum 40A V4) can
provide sufficient energy the servos to work effectively.
DEO Technology
The DEO (Driving effectiveness Optimization, more or less called "Active Freewheeling")
technology implemented into the ESC has many advantages.
● Quicker response to the throttle modification.
● greater driving effectiveness, much longer flight time.
● Lower ESC heat and a much more dependable procedure.
Reverse Brake
With the Reverse Brake mode enabled whenever landing can effortlessly
lessen the sliding distance pertaining to fixed-wing aircraft to simulate the
landing of an actual aircraft (within a brilliant brief distance). The traditional
Brake Mode, Proportional Brake mode, and Brake Disabled mode are
additionally available; the stopping system quantity is adjustable in normal braking system mode
during proportional braking system mode, the stopping system force are automatically
allotted based on the host to radio throttle stick.
Some Protections
Multiple safety features consist of, ESC thermal,
capacitor thermal (HOBBYWING-patented
technology), ESC overload, throttle indication loss
(or Fail secure), and low voltage cutoff effectively
prolongs the solution life the ESC.
Other Features
A separate development port to have in touch the programmer with this ESC allows user to
● Program ESC,
● check journey information include minimal voltage, maximum temperature, standardized RPM
and rate curve (in Heli Governing shop mode) regarding journey information recorded by the ESC,
● Upgrade ESC firmware With a multifunction LCD program package or a Wi-Fi Module & our
Apple/Android phone App.
Product Specification
Type
- Brushed/Brushless : BL
- High Voltage/Regular : Regular
Specifications
- Cont./Peak Present : 25A/40A
- Input : 3-6S Lipo
- BEC manufacturing : change Mode:6V/7.4V,3A
Wires & Connectors
- Input Wires : Red-16AWG-100mm*1/Black-16AWG-100mm*1
- Output cables : Black-18AWG-100mm*3
- Input Connectors : No
- Output Connecotors : 3.5mmGold Connectors (Female)
ESC Programing via
- Transmitter : perhaps not Supported
- LED Program Card : maybe not Supported
- LED Program Box : Not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : Separate Program Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 47x22x10mm
- Weight : 27g
