Futaba R149DP 9-Channel PCM Rx 50MHz/ 72MHz High w/o Crystal  [R149DP]

Futaba (#R149DP) - Futaba R149DP 9-Channel PCM Rx 72MHz High w/o Crystal

NOTES FROM OUR TECH DEPARTMENT
This is a R149DP 9-Ch 72MHz PCM 1024 Dual Conversion Receiver Without Crystal.
This is a higher Band (channel 36-60) receiver without a crystal (see NEEDS).

QUALITIES: Narrow-band spacing and dual transformation indicator filtering combined to
provide exceedingly clear, interference-free reception and
amazingly smooth, accurate control.
Designed for modelers who wants to make use of an individual radio transmitter
to travel a variety of model aircraft. Really pilots who are
utilizing computerized radios with multi-model memory.

INCLUDES: One R149DP Miniature 9 Channel 72MHz PCM 1024 Receiver

NEEDS: One FUTL58** Dual Conversion Receiver Crystal

SPECS: Narrow Band: 20KHz
Intermediate Frequency- 1st IF: 10.7MHz
2nd IF: 455kHz
Power needs: 4.8 to 6.0 volts (distributed to servos)
Current Drain: 15mA
Length: 2.16" (55.0mm)
Width: 1.27" (32.0mm)
Height: 0.82" (21.0mm)
fat: 1.2 oz (36g)
COMMENTS: 1024 Resolution just isn't right for Older PCM 512 methods.
For the transmitter/receiver crystal set, usage FUTL20**.
For the Tall Band, usage FUTL0903.
Special Notice about Frequency Changes-
*72MHz- Low musical organization channels 11 to 35; High band stations 36 to 60.
Receiver crystal networks (11-35 or 36-60) Within Each Band
Can become Changed, nor need a retuning the receiver.
*72MHz Regularity Band (low or high) the receiver cannot Be
Changed from low to high musical company, OR from high to low musical business without
sending it into Futaba Services for retuning.
*50MHz, 72MHz, 27MHz and 75MHz regularity Bands can not under any
circumstances be interchanged together. 72/75:receiver Must
be presented for retuning to your appropriate band. 50/27: can not do.
*50MHz, 27MHz and 75MHz receiver crystals could be changed anywhere
within the bands. There are not any actual high or low bands such
as the 72MHz musical organization has.
*Transmitter Crystals can't be changed to a different channel except
by an authorized solution center. It is actually against FCC instructions, and
illegal someone to improve a frequency determining component
of a transmitter. In the event that radio is not retuned, it could be a hazard
spectators, modelers or property, and void AMA protection.
*Check because of the community R/C club the frequencies found in your neighborhood
