Serpent SER400043 Medius X20FWD '21 carbon 1/10 EP [SER400043]

$Serpent SER400043 Medius X20FWD \'21 carbon 1/10 EP$

Price:

£240.50

Brand:

Serpent

Model:

SER400043

Condition:

Brand New

Quantity:

Write a review

$alt="Serpent SER400043 Medius X20FWD \'21 carbon 1/10 EP" title="Serpent SER400043 Medius X20FWD \'21 carbon 1/10 EP"$

Description

X20FWD story:
X20FWD ’21 is founded on the look of this X20 touring automobile.

The framework is established on the most used mid engine design, running a light-weight and strong 1-piece motor mount concept, minus the interference in the middle of your front part and back framework flex while however allowing center flex adjustability. The advantage for this reason style of design is allow maximum flex capabilities without impacting the drivetrain, meaning smoother energy distribution, more perseverance significantly less possibility of stripping spurs.

Suspension and Steering:
utilising the last 4 several years of development the X20 keeps the effective 4X proven pivot ball design setup allowing effortless and quick modifications to camber, toe, track width etc. A brand new 2-point steering crank system is really implemented for substantially more Ackermann modification, this alongside 4X geometry guarantees battle success!

Continuing from that which we have learnt from other RC platforms we now introduce a brand new suspension system supply design, enabling the capability to adjust arm flex! Numerous forms of carbon as well as other materials can be acquired as optional items to fine tune your X20’s hold and feel for whichever track you are on.

Comprehending the Eryx’s sway club system then combining with 4X ideas, the modern X20 minimal Centre of Gravity (LCG) Anti-roll club system can lower the sway club point regarding bulkhead without restricting the leverage point by connecting to your top arm. A fantastic system which achieves the best of being LCG while maintaining optimized performance.

The X20 features an even more old-fashioned approach to the surprise absorbers compared to the 4X, which makes it more user-friendly with less problem. We've predicated on producing the highest quality elements to guarantee the best fitment. Using our smoothest leak evidence X band we think the X20 shock absorber is a hobby changer!

Drive train ratio：
the theory regarding the X20FWD’21 wound up being constantly for stock competition, however with our new drive train ratio 38/21 it is easier to change kit ratio from 2 to 6.5

Battery mounting system enable various layout the total amount engine fat more go to focus, to keep security for making usage of a shorty battery pack in almost every feasible conditions.
DRIVESHAFTS:
The modern double ball bearing DJC shafts within the front, plus in a large part the newest ball raced CVD are included as standard. Providing ultra-smooth & peaceful torque application through the whole suspension system and steering travel
STEERING BLOCK:
preserving our effective dual pivot ball suspension system system system, we've got developed more modification to fine tune the maneuvering faculties.
Our brand-new Steering hub permits modification of Axle height, offset and Roll centre.
Utilizing these choices have really allowed we motorists to construct more component cost previously model.
Side lipo mount:
moreover contained in the X20FWD ’21 will be the component lipo mount.
Suspension:
Suspension Geometry Base on endeavor 4X touring vehicle,
the 2016-2017 IFMAR World Championship third location
2016 EFRA EC A-main finalist, 2017 many ETS A-main finalist
Top deck:
Medius concept top deck.
Steering rack and amazing Ackerman levers:
Steering rack and Ackerman steering system.
X20 12mm shocks:
The proven X20 50mm shock dampers with 12mm surprise human anatomy and universal shock-springs.
Motor/Servo mount:
motor & servo mount for complete flex control.
The engine and servo mount are attached with create a new approach to flex control.
Antiroll bars:
The ultra-low antiroll bars can be found in different sizes.
Suspension hands:
the main element and rear suspension system fingers originate from the effective X20 and will be used with or without optional carbon X stiffeners.
Battery mount options:
you need to use 3 various battery pack designs’ within the X20FWD’21 automobile, to create top fat circulation for every single track.
Center battery pack possition
The component battery power possition
Geardiff:
The nicely shaped straight back differential features moulded interior gears which makes it super smooth. The compact and light device holds an excellent amoun t of oil to provide constant performance through run. Its easily to own and re-mount the differential.
Upperarm mounts:
The suspension system brackets are adjustable with this specific 1pc suspension brackets shims available in 1mm and 2mm.
Bearing obstructs:
The proven X20 bearing obstructs with tradition Cam kind gear modification the perfect gear tension
Bumper and human anatomy mounts:
effect evidence bumpers and brand new body post spot especially created for the X20FWD.
Optional right back flex system:
straight back centre flex modification with butterfly design stiffener.
Overview regarding the primary needs
- Serpent Adjustable 50mm shock with 12mm
oversize shock human anatomy
- Serpent Linear larger bore springs
- Dampers include machined pistons for many of good use
feasible determination
- antique design ball raced LCG Anti-roll
club
- Pivot ball suspension system system system with little balls for
simpleness and free motion
- 4x design supply mount with adjustable castor
- effortless diff and spool treatment
- exceedingly low center of gravity
- new steering system for Ackermann
geometry
- engine mount owner with adjustable flex
- Re-Active back steering RRS system is
standard
- 1-piece shaft and motor mount allow simple
upkeep and changing of spur gears
- same heave damper front side and right back that'll be
installed beneath the diff/spool just above the
framework the lowest priced feasible center of
gravity
- Durable and smooth gear differential
- Battery mounting system enable various
design just how much
- Lightweight front aluminum spool with
hardened steel outdrives, bladeless
- Carbon fibre framework in 2.0mm difficult as
standard
- twin ball bearing DJC shafts inside the front side
created from spring-steel restrict wheel chatter
- furthermore size Kevlar reinforced drive gear and
super genuine operating pulleys, midshaft pulleys
made from hard anodized aluminum for maximum
durability.
