High Reliability & Durability
Built many loaded in tough and top-notch elements and in combination with cutting-edge
firmware, the XR8 PLUS has the capacity to deliver unmatched power and satisfaction even for
many hardcore of rushing applications, but is also responsive enough to shield itself
from damage as a result of overloading considering genuine punishment, overuse and/or people error.
Great Flexibility & Versatility
With strong torque and excellent production, the XR8 PLUS will certainly look after all
the ability hungry requirements that professional motorists require. The very
adjustable parameters linked to ESC enables motorists to take pleasure from smooth throttle
reaction as soon as the throttle/brake linearity is utmost required.
High Voltage included BEC
The XR8 PLUS could be the world’s first 1/8th ESC that integrates a HV built-in BEC with a production
up-to-date completely to 15 Amp and a switchable manufacturing voltage of 6V-7.4V. The high voltage BEC is
built to handle today’s high voltage servos on need utilized by 1/8th scale automobiles.
Ultra-Reliable Cooling System
HOBBYWING’s patented ac technology makes use of
proprietary heat-conductive copper pubs to rapidly and
efficiently move all inside temperature through MOSFET board
towards the built-in CNC machined billet aluminum heatsink
housing. The cooling fan adopts a shockproof mounting
which effectively decreases the chance of fan damage due
to vehicle’s regular jumps.
Virtually free of maintenance Operation
Because of exemplary thought and design put in
the XR8 PLUS, users might get a virtually upkeep
free working experience, as a consequence of higher level error
sensing and thermal security, a tremendously
tough housing, the greatest in heat-dissipation
technology and a certain shockproof fan mounting capable
to withstand something a racer can toss at it.
Effective Dynamic
Timing Algorithm
The world’s first 1/8th scale competition ESC which include
utilized powerful timing technology, with had great
successes in 1/10th scale touring vehicle tournaments for a long
time now, will somewhat expand the adjustable energy production
selection of the ESC while nonetheless keeping the entire system
effectiveness and smoothness.
Item Specification
Type
- Scale : 1/8th
- Brushed/Brushless : BL
- Sensored/Sensorless : SD
- Waterproof : No
Specifications
- Cont./Peak Present : 150A/950A
- Input : 2-6S LiPo/6-18 Cells NiMH
- BEC manufacturing : modification Mode:6V/7.4V,6A
Wires & Connectors
- Input Wires : Red-10AWG-200mm*1/Red-10AWG-150mm*1/Black-10AWG-150mm*1
- Output cables : Black-12AWG-200mm*3
- Input Connectors : No
- Output Connecotors : No
Fan
- Size : 30.0x30.0x10.0mm
- Voltage Quantity : 5-7.4V
- Powered by : operating on BEC
ESC Programing via
- SET Button on ESC : maybe not Supported
- LED Program Box : maybe not Supported
- LCD Program Box : Supported
- WiFi Module : Supported
- Program Port : FAN/Program Port
Firmware
- Firmware Upgrade : Supported
Size & Weight
- Size : 58.7x48.0x36.9mm
- Weight : 127g
Applications
- Motors : SL BL Motors
SD BL Motors - Vehicles : 1/8th Touring Car/Buggy/Truck Competitions
- KV Rating/T Count : 4S LiPo: KV≤3000
6S LiPo: KV≤2400
(40XX band of Motors)
