HOBBYWING XRotor PRO 25A Circular (Red Color) - 30902023  [HW-30902023]

Simple Installation

Motor is closely installed on the ESC, which considerably simplifies wiring and
installing the propulsion system.

Popular Choice

The mount is excellently worthy of the most popular 16mm
(outer diameter) carbon soluble fbre supply pipeline.

Exemplary Protection

The included framework from ESC and motor mount has
exemplary dustproof and splash evidence safety.

DEO Technology

The DEO (Driving effectiveness Optimization) technology implemented
in the ESC has its own advantages:
● Active braking. When reducing the throttle quantity, the motor will
decelerate quickly. This feature allows pilots to faster
perform all maneuvers like razor-sharp turns, altitude changes, and
unanticipated braking.
● Higher driving effectiveness, much longer trip time.
● Lower ESC heat and an even more dependable procedure .
* various companies call this technology by different names;
“SimonK” calls it “Comp_PWM”, “BLHeli” calls it “Dampaning-light”
and Kontronik calls it “Active Freewheeling”.

Simple to Use

Highly smart and adaptive default settings like
auto-adjusting timing for simple procedure.

Item Specification

Product Number

Specifications

• Cont./Peak Present : 25A/40A
• LiPo Cells : 3-6S LiPo
• BEC manufacturing : No

Wires & Connectors

• Input Wires : Red-18AWG-300mm*1/Black-18AWG-300mm*1
• Output cables : No
• Input Connectors : No
• Output Connectors : No

Features

• Throttle number Calibration : Supported
• Stick Programming : Supported
• DEO : Supported
• OneShot Mode : Not Supported
• Timing : Supported
• Light colors : perhaps not Supported
• Motor Rotation : maybe not Supported

Size & Weight

• Size : 89.3x44.5x20.9mm
• Weight : 50.5g(w/ Motor Mount)
