HOBBYWING XRotor Video Transmitter - 30505000  [HW-30505000]

Tiny Size & Exquisite Design

The STM32F405 MCU which features the effective computing ability and super-high
working frequency enables the FC to execute the PID and gyro with greater regularity.

Voltage-regulating Filter,
Adjustable Transmitting power &
Adjustable Voltage for Camera

The incorporated voltage-regulating filter isolates the disruption
for the power system through VTX to guarantee the image remains
clear and stable if the aircraft flies at higher rate. The
adjustable transmitting energy (0/25mW/200mW) and
stable production power guarantee long transmission distance.
For various applications, the supply voltage the camera
is adjustable between 5V and 12V.

48 Adjustable Frequencies & Race Bands Supported

The 6 regularity groups with 8 systems in each group form 48 frequencies; the frequency blood supply is
highly relevant to countless getting gear. One of the regularity teams, group D and team F are
regularity groups for competition; users can use the 8 frequencies in identical team in addition
without fretting about interference.

Stack-up Installation Supported

When combining the VTX due to the Hobbywing F4 flight controller
and XRotor Micro 40A 4-in-1 ESC, the installation is extremely
incorporated, easy and simple convenient, and makes the aircraft
more appropriate towards FPV Racing.

Item Specification

Part No.

• 30505000

Basic Features

• Input Voltage : 7-25V
• Current : 70mA / 100mA / 250mW @ 12V
• Output Voltage : 5V/12V Adjustable (limited to powering the webcam)
• Transmitting power : 0/25mW/200mW Adjustable
• Transmitting Frequency Range : 5.3GHz-5.9GHz
• Transmitting Frequencies : 48 Frequencies Adjustable
• Antenna Connector Type : MMCX-to-SMA (a MMCX-to-SMA cable is roofed in box)

Size & Weight

• Size : 36x36mm
• Mounting Holes : 30.5x30.5mm
• Weight : 5g
